Oralite 5910DP High-Intensity Prismatic Grade

Designated as UV Digital Print Media, Oralite 5910DP High-Intensity Prismatic Grade is EN12899-1 & UKCA certified at RA2.

Take a look at the colours & sizes we distribute.
Download: 5910 Spec Sheet

Send A Trade Inquiry

Want to know more about this material, our pricing or trading terms? Fill in this form with your details and we'll get back to you.

SKU: 5910dp Category: Tag:

Description

Oralite 5910DP High-Intensity Prismatic Grade is designed for UV Printing permanent road signs. Including large scale advanced directional assemblies that need to perform over their entire life cycle. For compliance, Oralite 5910DP must be laminated with 5061 overlay for durability and to meet its certification. As well as a transparent overlay, there’s a range of additional protective laminates, films and inks.

Featuring a 10-year outdoor service life, Oralite 5910DP comes in white or fluorescent yellow-green. And in addition to this Digital Print reflective film, there’s a standard version 5910.

Orafol Website: Oralite 5910DP High-Intensity Prismatic Grade – film details, data sheet, certificates & application instructions.

Oralite 5910DP Specs

Brand: Oralite
Type: Retroreflective Film
Roll Width: 1235mm
Roll Length: 50 metre rolls
ST Colours: 0.240mm thick
FL Colours: 0.315mm thick
Variant: Digital Print version of 5910

Material Details

  • Reflective Class: RA2 – UKCA/CE Certified*
  • Standard: EN 12899-1 / NHSS
  • Acrylic Film with Polypropylene Liner
  • Technology: Prismatic
  • Durability: 10 year life
  • Colours: 1 Standard / 1 Fluorescent
  • Pressure Sensitive Adhesive for Metallic Surfaces

Compatible Products

  • Digital Ink: 5019i (uv) / 5017 (eco)
  • Transparent Film Overlay: 5061
  • Anti-Graffiti Overlay: 5095
  • Anti-Dew Overlay: 5090
  • Lettering Film: 5081

* When Laminated with 5061 Transparent Film.

Colours & Pattern

Colours & patterns shown below are for illustration purposes and may not match actual products. Click for large images.

Standard Colours
Fluorescent Colours
Watermarked - Icon
