Oralite UV Traffic Printer

An advanced digital printing system, that’s optimised for Oralite Reflective Films, R2R & Rigid Substrates.

Oralite - small logoAGFA - diamond logo

A Cutting-Edge Answer to EN12899-1 & BS8442 Traffic-Sign Production

The wide-format Oralite UV Traffic Printer is designed for sign makers that handle board & roll-to-roll jobs. This market-leading solution is perfect for producing traffic control and guidance signs. Thanks to its agile media-handling capabilities and air-cooled UV LED lights. Not to mention, having optimised profiles for Oralite Reflective, traffic colours & UV Ink. Which combine to quickly print signs compliant to EN12899-1 or BS8442, while saving on ink & energy usage.

Play Video

Oralite UV Traffic Printer

Preparing to Start Printing
The Print Head and Command Centre
Roll-to-Roll Oralite Reflective Printing
Lifting the Take-Up Roll

Optimised for Oralite

Compatible with Micro-Prismatic & Glass-Bead Films from Class-1 to R3C

UV LED LIGHTS

Reduces Costs, Energy Use and Time.

R2R & BOARD

Handles Roll-to-Roll & Direct 2 Substrate.

INK SAVING

Thin-Ink Technology Lowers Consumption.

COMPLIANT

Produces EN12899 & UKCA Traffic Signs.

ROBUST ENGINEERING

Designed for High & Sustained Workloads.

Produce Traffic Signs with 12yr Durability

With an array of day-to-day features, the Oralite UV Traffic Printer is ideal for sign shops. Thanks to the AGFA printers reinforced belt drive, vacuum system and shuttle beam, that bring high accuracy and print quality. Print heads which guarantee good solids, tonal rendering and fine text reproduction. Agile media handling that covers 1.65m widths, roll-to-roll jobs and substrates up to 40mm thick. And specialist Oralite 5019i UV Inks, which deliver long-term durability on Oralite Reflective.

Boasting a touch screen interface, the command centre has multi-language support. Alongside workflow software like Asanti RIP which has ready to use ink & colour profiles. During production runs, ink levels are monitored automatically & tanks are easy to access. White is managed separately, kept under-pressure and constantly stirred to keep a perfect mix. Finally, inflatable airshafts on the rollers provide perfect tension and wrinkle-free printing.

HIGH DURABILITY

Print Signs with a 12 year Exterior Durability

Print Signs with a 12 Year Durability

TRAFFIC COLOURS

Conforms to EN12899-1 & BS8442 Regulations

Traffic Colours that Conform to Regulations

QUICK DRYING

Prints Dry Instantly via Low Voltage UV LED Lamps

UV Prints Dry Instantly

OPTIMISED

For High Performance Oralite Inks, Films & Overlay

Optimised for Oralite Reflective, Inks & Overlay

LED Lamps: Fast Drying & Low Energy

Of course, the air-cooled UV LED lamps on the Oralite UV Traffic Printer deliver results that effect business turnaround, costs & environmental impact. Not only do they provide instant on or off performance, for the quick-drying of printed Oralite 5019i UV Ink. But their low-heat emissions allow the use of more thermally sensitive materials & films. And they provide cost-savings due to their low-power needs and long-life. Especially when it’s combined with the lack of drying and venting equipment required.

Specification System Details

Print Engine
Printer Model
Anapurna H1650i LED Express
Size & Weight (HxWxL)
1.66x3.91x147m & 1,020kg
Electricity
380V 3-Phase Star Connection with Neutral Wire
Compressed Air
Oil-Free 160l/min Compressor
Productivity
Oralite Traffic-Sign Mode
22m²/h | 236ft²/h
Orajet Graphic-Mode
28m²/h | 301ft²/h
Head/Nozzles
6 KM Heads with 1024 nozzles/head @ 30 picolitre
UV Ink
Oralite 5019i
Ink Rating
GreenGuard Gold
UV LED Lamps
Air-Cooled 16 Watt/cm² UV LED Lamps
RIP/Workflow Software
Asanti RIP 4.0 & Internal Image Server
Profiles
Traffic-Sign Media/Ink
Image & Text Quality
Resolution
Up to 720x1400 dpi
Text Quality Positive
4pt | ORAFOL Ink 6pt
Text Quality Negative
6pt | ORAFOL Ink 8pt
Media Handling
Max Width
165cm
Borderless Width
Up to 160cm
Board Printing
A2 Landscape 60x42cm
Max Rigid Length
3.2m with Tables
Max Rigid Weight
Up to 10kg/m²
Max Rigid Weight
Up to 50kg
Max Weight (RTR)
Up to 50kg
Max Diameter (RTR)
Outside 36cm
Media Thickness
0.2mm to 45mm

Downloads UV Traffic Printer

For details of the Oralite UV Traffic Printer, take a look at the video & links below. Please note some PDF’s are reduced in size for the Web, larger high-quality versions are available on request.

Oralite UV Traffic Printer - Video
UV Traffic Printer - Flyer
AGFA - Hybrid Anapurna LED Series
Orafol Europe - UV Printer
Oralite UV Traffic Printer - Brochure
Orafol UV Traffic Printer - Video
Oralite 5090i UV Digital Ink

Lift Your Sign Production Higher with the Oralite UV Traffic Printer

Get an advantage over your competition with the Oralite UV Traffic Printer. Not only is it optimised for traffic control and guidance signs. But your production will also benefit from its Oralite Reflective compatibility & support for rigid substrates.
